| Specifications |
| Model |
CS-C8c-R100-1K2WKFL |
| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4mm@ F1.6, viewing angle: 44° (Vertical), 84°(Horizontal), 100° (Diagonal) |
| PT Angle |
Pan: 350°, Tilt: 80° |
| Minimum Illumination |
0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories) |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto switch |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| Black & White Night |
30m / 98ft |
| Video & Audio |
| Max. Resolution |
1920 × 1080 |
| Frame Rate |
Max: 30fps; Self-Adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| H.265 Type |
Main Profile |
| Video Bit Rate |
Ultra-HD; Hi-Def; Standard. Adaptive bit rate. |
| Audio Bit Rate |
Self-Adaptive |
| Network |
| Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
Supports 20 MHz |
| Security |
WPA-PSK / WPA2-PSK |
| Transmission Rate |
11b: 11Mbps, 11g: 54Mbps,11n: 72Mbps |
| Wi-Fi Pairing |
AP pairing |
| Protocol |
EZVIZ Cloud Proprietary Protocol |
| Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
| Wired Network |
RJ45 × 1(10M/100M Adaptive Ethernet Port) |
| Storage |
| Local Storage |
MicroSD Card Slot (Up to 512GB) |
| Cloud Storage |
EZVIZ CloudPlay Storage |
| Function |
| Smart Alarm |
AI-Powered Human Shape Detection / Motion Detection |
| Auto Tracking |
Supports |
| Customized Alert Area |
Supports |
| Two-way Talk |
Supports |
| Preset Locations |
Supports |
| General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| General |
| Operating Conditions |
-30°C to 50°C (-22 °F to 122 °F), humidity 95% or less (non-condensing) |
| IP Grade |
Weatherproof Design |
| Power Supply |
DC 12V / 1A |
| Power Consumption |
MAX. 12W |
| Dimensions |
102.27 × 128.61 × 147.05 mm (4.03 × 5.06 × 5.79 inch) |
| Packaging Dimensions |
140 × 140 × 192 mm (5.51 × 5.51 × 7.56 inch) |
| Weight |
Net Weight: 480g With Package: 786g |
| In the box |
| In the box |
- C8c 1080p Camera |
| - Drill Template |
| - Screw Kit |
| - Waterproof Kit |
| - Power Adapter |
| - Regulatory Information |
| - Quick Start Guide |
| Certifications |
| Certifications |
CE / UKCA / UL / WEEE / RoHS / REACH |
