RØDE XLR WIRELESS SYSTEM FOR REPORTING MICROPHONES

ROD/NEWSSHOOTER

Status: In stock

CA$559.00

Description

Description

RØDELink represents the next generation of digital wireless systems. Using a Series II 2.4GHz digital transmission with 128-bit encryption, it is able to constantly monitor and hop between frequencies to maintain the strongest possible signal level at a range of up to 100 metres* (over 100 yards).

The RØDELink Newsshooter Kit provides everything you need to start shooting video wirelessly with XLR microphones, including a camera-mounted receiver and an XLR transmitter. The receiver (RX-CAM) features an OLED display with information on level, battery status (receiver and transmitter), mute and channel selection.

The unit can be mounted on a standard camera shoe mount, 3/8" thread or belt-clip, and for added versatility the shoe mount can be located in one of two positions.

The transmitter (TX-XLR) easily connects to handheld presentation microphones as well as shotgun microphones, with a 3.5mm input and headphone output.

Specifications

Specifications

What's in the Box
Wireless Transmitter for XLR Microphones

1 x RØDELink TX-XLR

Camera-Mounted Wireless Receiver

1 x RX-CAM





Transmission Type




2.4GHz Fixed Frequency Agile System
System Dynamic Range
112dB
Range (Distance)
Up to 100m
Frequency Range
35Hz - 22kHz
Maximum Output Level
1v Rms (2.8v P-p)
Maximum Input Signal Level
1v Rms (2.8v P-p)
Maximum Latency
4ms
Power Source

RX-CAM - 2 X AA Battery Or MicroUSB

TX-XLR - 2 X AA Battery, Sony NP-F Battery Or MicroUSB

Antenna
Internal
Output Connection
RX-CAM - 3.5mm TRS Locking Jack Socket - Dual Mono
Input Connection
TX-XLR - XLR With Locking Collar, 3.5mm TRS Locking Jack Socket
Output Impedance
RX-CAM - 300Ω
Input Impedance
TX-XLR - 1kΩ (XLR), 10kΩ (3.5mm)

Dimensions (mm)


RX-CAM - 111 (L) X 65 (W) X 52 (H)

TX-XLR - 120 (L) X 45 (W) X 45 (H)

Weight (g)

RX-CAM - 190

TX-XLR - 222
